DESCRIPTION
Dual mono class D power amplifier based on two HYPEX NCx500 modules of the new Ncore X series. Thanks to this technology the amplifier is ultra-linear, has noise and distortion levels that are almost non-existent (even lower than those typical of class A or A / B of the highest quality) and also can handle the most difficult loads thanks to an ultra-low output impedance. Each amplifier module is powered by one Hypex SMPS1200A700 PSU.
NEUTRAL AND CLEAR POWER AMPLIFIER
NEW BUFFER STAGE
OPA 1612 + HxR DISCRETE VOLTAGE REGULATORS
The new NCx500 modules have a built-in and optimized buffer stage. The buffer is based on the OPA1612 supplied by the well-known Hypex HxR discrete voltage regulators. In this way, the following improvements are achieved:
-
ultra low noise
-
higher bandwidth
-
excellent CMRR
-
low load independent output impedance
DUAL MONO CONFIGURATION TO GET THE MOST OUTPUT OF THE NCX500
The amplifier is configured in DUAL MONO: each channel is equipped with its own HYPEX SMPS1200A700 power supply dedicated to the respective power stage amplifier Hypex NCx500. The two channels are therefore completely independent and have in common only the AC power supply and the relative control board. Each SMPS1200A700 power supply is oversized compared to the NCx500 module as it is capable of delivering 1200W at 20hz.
RCB OPTION . It is possible to add, for each channel, the RCB (Rouge Connection Board) which allows to have double XLR and RCA inputs. It is a passive module made with quality components.
balanced input
(XLR only)
RCB option
(XLR + RCA input)
eXceptionally good
Technology
2 x Hypex NCx500
Technical specifications
Output power: 2x700W(2Ω), 2x700W (4Ω), 2x380W (8Ω)
Distorsion THD + N: 0,0006%
Power Bandwidth: min. 35Khz
Frequency Response: 0-75Khz
SNR: 136dB
PSRR: 85dB
Gain (buffered): 26,8 dB
Gain (unbuffered): 11,5 dB
Output noise: 7µV
CMRR: 65db all frequency
Maximum output current: 28A
Mains: 190-250Vac (95-130Vac on request)
Inputs: balanced (+unbalanced with RCB option)
Trigger (option)
Casing: black metal with aluminium front and rear panel (2U)
Measurements: 435x300x80mm
Weight: 9,5kg
